Streamfeeder XT-1200 Dropper

The fastest card/envelope dropper in the marketplace! The Streamfeeder XT-1200 Dropper is designed to be a “high-speed” flexible solution for packaging operations pursuing greater productivity through automation. Ideal for use with wrapping systems, cartoners, L-sealers, and many other types of packaging equipment that require dependable automation for product counting and accumulating.

At the core of the Streamfeeder XT-1200 Dropper is our patented Differential Friction Technology™ which ensures package integrity through precision product separation and singulation.

The powerful Streamfeeder XT-1200 Dropper will effectively feed, count, and accumulate products at high-speed producing high levels of automated productivity. Integrate two or more Streamfeeder XT-1200s on an infeed conveyor to create the ultimate high-speed card/envelope collating system.

The Streamfeeder XT-1200 Dropper is easy to learn and simple to operate.

(click to view video)

Streamfeeder Greeting cards









technical data

Maximum Product Size:

9 W x 7 L in (229 x 178 mm)

Minimum Product Size:

4.5 W x 4 L in (114 x 101 mm)
Min/Max Product Thickness: .003-.5 in (.076-12.7 mm)
Batch Size: Maximum accumulation thickness 1 in (25.4 mm)
Belt Speed : 13,800 in/min (350,520 mm/min)
Air Requirements: 5 CFM
Electrical Requirements: 115/230vac, 50/60Hz
Weight: 260 lbs. (117.9 kg)
