Streamfeeder V-710BC

The Streamfeeder V-710BC provides dependable One-Shot Feeding and Batch Count
Feeding of a wide variety of products. Ideal for collating and mail inserting applications that operate at speeds up to 100 cycles per minute. Simple tool-less adjustments for quick setups and changeovers.

(click to view video)

Streamfeeder Collating

Streamfeeder Automatic Wrapping








Technical Data
Maximum Product Size: 12 W x 12 L in (305 x 305 mm)*
Minimum Product Size:
3.75 W x 3.75 L in (95 x 95 mm)
2.5 W x 2.5 L in (63 x 63 mm)
Min/Max Product Thickness: .003-.750 in (.076-19 mm)
Belt Speed: 4000 in/min (101,600 mm/min)
Batch Size: 1-50 pieces
Electrical Requirements: 115/230vac, 50/60Hz, 3A
Weight: 43 lbs. (19.5 kg)
*Optional product size available
