Streamfeeder V-1000

Introducing the new Streamfeeder V-1000 Mailing Feeder. The Streamfeeder V-1000 is the latest addition to the Value Series. And now it's CE certified.

The Streamfeeder V-1000 is the result of extensive research throughout the mailing industry to define what mailing service companies in the industry desire most in a continuous feeder for applications such as ink jet printing, tabbing, and labeling. The research has yielded a no-frills product that feeds a wide variety of materials with exceptional alignment qualities. The importance of straight feeding and minimizing skewing can help improve USPS® MERLIN™ verification results, leading to significant savings for a mailing service company.

Applications:
(click to view video)

Streamfeeder Mail Processing

Streamfeeder Reinforcing Machines

















The new V-1000 (patents pending) includes features that provide quick tool-less setup, quick make-ready, and easy maintenance. For example, feed belts can be repositioned with the use of single knob adjustments, and belts can be replaced quickly. The side guides also feature single knob adjustments and can be quickly removed without tools. Two independently adjustable separators help improve feeding of uneven materials. Newly designed material levelers also feature single knob adjustments. In addition, there is a hinged panel for easy access to controls and electronics.

Technical Data
Maximum Product Size: 12 W x 12 L in (304.8 x 304.8 mm)*

Minimum Product Size:

2 W x 3 L in (50.8 x 76.2 mm)*
Min/Max Product Thickness: .003-1.0 in (.076-25.4 mm)
Belt Speed: 7800 ipm (198,120 mm/min)
Electrical Requirements: 115/230vac, 50/60Hz, 3A
Weight: 47 lbs. (21.3 kg)
*Optional product size available
