Streamfeeder Tip-On Systems

Simplicity and easy setup. That was the goal was when we set out to design the Streamfeeder Converge 900 Tip-On Solution. Utilizing servo motor technology, products can be precisely placed at speeds up to 18,000 pieces per hour, with accuracy to +/- 1/16" (1.5mm). The Streamfeeder Converge 900 is offered as a complete turnkey system or can be added to your existing Vacuum Transport.


Tip-On System		Converge 900

Applications:

(click to view video)

Streamfeeder Gift Cards Onto a Hanging Backer

Streamfeeder Promotional Documents Onto Magazines

Streamfeeder Folded Documents Onto Cartons / Boxes

Streamfeeder Embossed Credit Cards Onto Folded / Unfolded Paper Carriers

Innovative Servo Motor Technology enables you to singulate and dispense the widest range of material types and sizes. Its modular design allows the Streamfeeder Converge 900 to be integrated with a variety of systems. And, most importantly, the Streamfeeder Converge 900 is easy to learn and simple to operate, helping you increase productivity and reduce cost.

Our Tip-On Solutions are available as Turn-Key Systems (consisting of a carrier feeder, Transport System, glue system, and delivery conveyor) or as specialty feeding units integrated to existing Host Systems (such as Ink Jet Bases, Folding Machines, Vacuum Bases, or Folding / Gluing Equipment).

Technical Data (Converge 900)
Maximum Product Size:	7 W x 6 L in (177 x 152 mm)
Minimum Product Size:	2 W x 2.5 L in (50 x 63 mm)
Min/Max Product Thickness:	.003-.250 in (.076-6.35 mm)
Belt Speed:	24,000 in/min (609,600 mm/min)
Placement Tolerance:	Steady speed up to +/- 1/16 in (1.58 mm)
Electrical Requirements:	115/230vac, 10A
Air Requirements:	4-6 CFM
Weight:	60 lbs. (27.22 kg)
