Streamfeeder ST-1250

The Streamfeeder ST-1250 is our most popular and versatile model. With our intelligent system controller incorporated into its stainless steel enclosure, the Streamfeeder ST-1250 gives you the flexibility of using it in stand-alone applications as well as integrating into other systems. The Streamfeeder ST-1250 is capable of handling a wide variety of products, from single sheets to thick magazines.
Applications:
(click to view video)

Streamfeeder Collating

Streamfeeder Product Insertion
















Technical Data
Maximum Product Size: 12 W x 14 L in (298.45 x 355.6 mm)

Minimum Product Size:
(optional):

3.75 W x 3.75 L in (95.25 x 95.25 mm)
2 W x 2.5 L in (50.8 x 63.5 mm)
Min/Max Product Thickness: .003-1.0 in (.076-25.4 mm)
Belt Speed: 5500 in/min (140,000 mm/min)
Electrical Requirements: 115/230vac, 50/60Hz, 6A
Weight: 89 lbs. (40.367 kg)
