Streamfeeder Reliant 1500

The compact Streamfeeder Reliant 1500 combines flexible performance with superior feeding to precisely separate, singulate, and present many types and sizes of product to your inserter's gripper jaw. Job setups and changeovers are easily and quickly accomplished. A large capacity hopper is conveniently loaded from the front or back. The brushless and clutch-free motor provides dependable feeding performance.

Applications: (click to view video)
Streamfeeder 6 x 9 Gripper Arm Envelope Inserters
Streamfeeder Phillilsburg, Inserco, EMC, AMOS, Kern, and similar Inserters
Streamfeeder Z-Fold Sheets, Slick Stock, Payment Booklets, and other products that are typically fed with difficulty on an Inserter





  Features
  • Reliable product separation
  • Tool-less adjustments for easy setups and changeovers
  • Compact 10 inch width allows side-by-side mounting
  • Sealed precision bearings never require lubrication
  • Handles most insert types, sizes, and thicknesses
  • Easy to learn and operate
Technical Data
Maximum Product Size: 9.25 W x 6 L in (235 x 152 mm)
(contact us for longer insert length)
Minimum Product Size: 2.125 W x 2.25 L in (54 x 57 mm)
Min/Max Product Thickness: .003-.250 in (.076-6.35 mm)
Belt Speed: 1000 ipm (25,400 mm/min)
Electrical Requirements: 115/230vac, 1A
Weight: 23 lbs. (10.43 kg)
